Product Overview
- LED, Incandescent, Halogen and Strobe light source
- Six lens colors available
- Two optional IP54 sounders available:
- Multi-tone module, eight available tones
- Sounder modules provide 89dB @ 1 meter/79dB @ 10 ft.
- Base and light modules are IP65 rated
- Suitable for indoor and outdoor applications
- Option for panel or conduit mounting
- NEMA Type 3R and 4X enclosure
- Optional mounting not included
Edwards 102 Series StackLight is a unique audible-visual signaling device that may contain up to five light modules and a pulsating horn in a single, integrated stack. Two optional sounder modules are also available. The StackLight diffusion optic lens allows viewing from close up while still projecting the light through use of a built-in projection ring.
The lens modules are available with LED, Incandescent, Halogen or Strobe light sources. Options for steady-on or flashing are available. The 102 Series offers a shorter base for panel or conduit mounting as well as a taller base, designed for use with a sounder module.
General Information
Name : Edwards Signaling 102SIN-RGA-G1 102 Series StackLight , Edwards Signaling
Category : Emergency Lights, Exit Lights & Lenses
UPC Code :
Country of Origin : United States. Country of origin is subject to change.
Specifications
General Information
ADI Part Number : ED-102SINRGG
Brand Name : Edwards Signaling
Manufacturer Part Number : 102SIN-RGA-G1
Product Line : Stacklight
Product Name : 102 Series StackLight
Product Series : 102
Product Type : Security Strobe Light
Environmental Conditions
Sound Emission : 79 dB, 89 dB
Physical Characteristics
Width : 3"
Miscellaneous
Country of Origin : US
Indoor/Outdoor : Indoor, Outdoor
