Belden CAD1105007 CAT6 Patch Cable, 28/4 Stranded, UTP, CMR, T568A/B-T568A/B, 7' (2.1m), Green
CAD1105007
|7B-CAD110502
Cable Length: 7'
Color: Green
Shielding: No
Shop All Belden
Belden CAD1105007 CAT6 Patch Cable, 28/4 Stranded, UTP, CMR, T568A/B-T568A/B, 7' (2.1m), Green
CAD1105007 | 7B-CAD110502
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
The Belden CAD1105007 is a CAT6 patch cable designed for superior performance and flexibility. Measuring 7 feet (2.1 meters) and dressed in a vibrant green, it features a stranded 28/4 UTP design, supporting PoE and Cisco UPOE technologies. This cable is highly bendable, ensuring convenient installation even in tight spaces. Its advanced Power-sum Near End Crosstalk (PSNEXT) and Power Sum Attenuation to Crosstalk Ratio, Far-End (PSACRF) capabilities enhance signal integrity. Additionally, Power-sum Alien Near End Crosstalk (PSANEXT) and Attenuation To Alien Crosstalk Ratio Far End (PSAACRF) provide robust interference resistance. Ideal for reliable, high-speed data transmission, this cable is a smart choice for network setups. Upgrade your connectivity with this versatile and efficient patch cord today!
Main Features
- Stranded
- PoE
- Cisco UPOE
- Bendable
- Power-sum Near End Crosstalk (PSNEXT)
- Power Sum Attenuation to Crosstalk Ratio, Far-End (PSACRF)
- Power-sum Alien Near End Crosstalk (PSANEXT)
- Power-sum Attenuation To Alien Crosstalk Ratio Far End (PSAACRF)
General Information
Name: Belden CAD1105007 CAT6 Patch Cable, 28/4 Stranded, UTP, CMR, T568A/B-T568A/B, 7' (2.1m), Green
Category: Belden, Wire & Cable, Network Patch Cords, Category 6 Patch Cords
UPC Code: 611589229739
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number 7B-CAD110502 Brand Name Belden Country of Origin US Manufacturer Belden CDT, Inc Manufacturer Part Number CAD1105007 Package Type Bag Packaged Quantity 6 Product Name Cable Assemblies - CAT6A Performance Modular Cord Product Type Network Cable
American Wire Gauge 28AWG Cable Rating Riser Cable Type Category 6a Conductor Material Bare Copper Connector on First End RJ45 Connector on Second End RJ45 Device Supported Network Device, Patch Panel Jacket Type Standard Shielding No Solid or Stranded Stranded
Certifications & Standards c(UL)us Listed, FCC Part 68, IEC 60603-7, Subpart F
Operating Temperature (T-T) -10-60°C Storage Temperature (T-T) -40-70°C
Cable Length 7.00' Color Green Insulation Material High-density Polyethylene (HDPE) Jacket Material PVC
Current Rating 1.50A
Length 7.00'
Environmental Certification China RoHS, EU RoHS, RoHS Environmentally Friendly Yes Features Bendable, Cisco UPOE, PoE, Power Sum Attenuation to Crosstalk Ratio, Far-End (PSACRF), Power-sum Alien Near End Crosstalk (PSANEXT), Power-sum Attenuation To Alien Crosstalk Ratio Far End (PSAACRF), Power-sum Near End Crosstalk (PSNEXT), Stranded
