Product Overview
4Ohm/25V/70.7V/100V Output
Specifications
ADI Part Number V4-TSDPA20VG Manufacturer Part Number TSD-PA20VG Product Model TSD-PA20VG Product Name TSD-PA20VG Mono Power Amplifier Product Series TSD Product Type Amplifier
Audio Channels 1 Impedance 4 ohms
Maximum Frequency Response 20 kHz Minimum Frequency Response 40Hz RMS Output Power 20W Total Harmonic Distortion (THD) 15%
Operating Power Consumption 11.70W
Number of Audio Inputs 2
Color Black Depth 5.2" Height 1.5" Weight 5.82oz Width 4"
Input Voltage 24V DC
Limited Warranty 3-Year
Country of Origin CN Environmental Certification RoHS Features 4O/25V/70.7V/100V Output, Cable Management System, Compact Chassis Design, Energy efficient, Input Signal and Peak Indicator LEDs, One (1) Balanced Input, Po, Removable Level Control with Set-It-And-Forget-It Security Cover, Removable Phoenix Style I/O Connectors
