Securitron AQL104-2D8PE1 AQL104 Series Intelligent Power System, 24V DC, 10A

AQL104-2D8PE1|SN-AQL1042DP
Shop all Securitron by ASSA ABLOY

Securitron AQL104-2D8PE1 AQL104 Series Intelligent Power System, 24V DC, 10A

AQL104-2D8PE1|SN-AQL1042DP

Sign In for Dealer Pricing

Become an ADI Customer
Securitron by ASSA ABLOY

Securitron AQL104-2D8PE1 AQL104 Series Intelligent Power System, 24V DC, 10A

AQL104-2D8PE1 | SN-AQL1042DP

Please sign in to view pricing and availability and to add to cart.

Overview
Specifications
Documents

Product Overview

The UL listed, Securitron AQL104 Series of single voltage, switching power supplies provides 10 Amps at 24 VDC which can be expanded to support up to 16 outputs and offers a dedicated fast battery charging circuit. Available with factory or field configured optional (B100) multi-voltage and (NL4) network monitoring & control.

Main Features

  • Low battery cutoff protects batteries from deep discharge
  • Dedicated fast charger prolongs battery life
  • Enhanced surge immunity for input/output protection
  • LockSafe™ keeps locks cooler by providing a separate, dedicated battery charging circuit
  • OutSmart™ technology provides dual-color LED visual notification which prevents applying incorrect voltages to the power supply: (Green: 12 V | Blue: 24 V)
  • Auxiliary is Class 2, power limited
  • Mix and match UL Listing
  • Instant auto-switch to battery on AC loss
  • Expandable up to 16 outputs in the standard enclosure
  • Multi-voltage with Securitron B100 Module

    • General Information

    Name:Securitron AQL104-2D8PE1 AQL104 Series Intelligent Power System, 24V DC, 10A
    Category:Securitron by ASSA ABLOY, Batteries & Power Supplies, Power Supplies & Boards, Power Supplies
    UPC Code:784607049586
    Country of Origin:United States. Country of origin is subject to change.

    Specifications

    Product Documents and Resources

    Product Data Sheet
    Installation Instructions
