Pelco FMCI-PF1POE MEDIA Converter SFP, 100m, Power Over Ethernet

FMCI-PF1POE | PE-FMCIPF1PO

Please sign in to view pricing and availability and to add to cart.

Overview
Specifications
Documents

Product Overview

The FMCI-PF1PoE Ethernet media converter is designed to transmit and receive 10/100 Mbps or 10/100/1000 Mbps data over optical fiber through user-selectableFSFP options. It require interchangeable small form-factor pluggable (FSFP) modules (ordered separately) for fiber type, distance, and connectors. It transmit and receive a single channel of Ethernet data, and support IEEE 802.3at Class 1-4 as Power Sourcing Equipment (PSE) with up to 30W at 48V DC. The electrical interface autonegotiates between 10 Mbps, 100 Mbps, or 1000 Mbps Ethernet rates without any adjustments. The optical interface operates at a 100 Mbps Ethernet rate. It designed to operate in extreme temperatures. Built-in indicator LEDs display operating status. The optical transmission of Ethernet-compatible IP camera surveillance video makes it ideal for transportation, airport, and college campus applications.

Main Features

  • Electrical Port Supports Autonegotiation for 10 Mbps, 100 Mbps, or 1000 Mbps, Full-Duplex or Half-Duplex Data
  • Supports Distances up to 120 km (74.5 mi) Using Interchangeable Small Form Factor Pluggable (FSFP) Modules for Compatibility with a Wide Range of Optical Fibers, Optical Connector Types, and Optical Transmission (Must Be Ordered Separately)
  • IEEE802.3at Class 1-4 Power over Ethernet (PoE) 30 W at 48V DC
  • Automatic Medium Dependent Interface/Medium Dependent Interface Crossover (MDI/MDI-X) Operation
  • Designed to Meet NEMA TS 1/TS 2, and Caltrans Traffic Signal Control Equipment Environmental Standards
  • Voltage Transient Protection on All Power and Signal Input/Output Lines Provides Protection from Power Surges and Other Voltage Transient Events
  • LED Status Indicators for Monitoring All Critical and Normal Operating Parameters
  • Compliant with IEEE 802.3 Standards

    • General Information

    Name:Pelco FMCI-PF1POE MEDIA Converter SFP, 100m, Power Over Ethernet
    Category:Pelco by Motorola Solutions, Data Comm & Networking, Network Adapters, Media Converters, ADI Pro Rewards
    UPC Code:700880322901
    Country of Origin:United States. Country of origin is subject to change.

    Specifications

    Product Documents and Resources

    Product Data Sheet
    User Manual
