Panduit DNF14-250FIMB-Q Pan-Term Loose Piece Disconnect, Blue
DNF14-250FIMB-Q
|P9-4250FIBQ
Shop All Panduit
Panduit DNF14-250FIMB-Q Pan-Term Loose Piece Disconnect, Blue
DNF14-250FIMB-Q | P9-4250FIBQ
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
The vibration resistant male tab disconnect is made of brass and is nickel-plated. It is fully insulated in a blue, oversized nylon housing. It has a tab size of 0.250 x 0.032" (6.3 x 0.8 mm) and supports a wire range of 16-14 AWG (1.5-2.5 mm²). It is 0.91" (23.1 mm) long and 0.45" (11.4 mm) wide. The disconnect has a standard barrel configuration and a butted seam barrel. It comes in bottles of 25.
Main Features
- Features terminal connector
- Nickel contact plating
General Information
Name: Panduit DNF14-250FIMB-Q Pan-Term Loose Piece Disconnect, Blue
Category: Panduit, Data Comm & Networking, Cable Connectors, Splice Connectors
UPC Code: 74983120352
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number P9-4250FIBQ Brand Name Panduit Manufacturer PANDUIT CORP Manufacturer Part Number DNF14-250FIMB-Q Packaged Quantity 25 Product Name Terminal Connector Product Type Terminal Connector
Color Blue Material Brass Width 0.50"
Limited Warranty 1-Year
Environmentally Friendly Yes Features Flame Retardant
