Lantronix E-100BTX-FX-06-NA Stand-Alone Fast Ethernet Media Converter 100Base-TX to 100Base-FX
E-100BTX-FX-06-NA
|P6-E1BTXFX6N
Shop All Lantronix
Lantronix E-100BTX-FX-06-NA Stand-Alone Fast Ethernet Media Converter 100Base-TX to 100Base-FX
E-100BTX-FX-06-NA | P6-E1BTXFX6N
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
The E-100BTX-FX-06 is a stand-alone media converter that provides an interface between 100Base-TX ports and 100Base-FX ports, allowing users to integrate fiber optic cabling into 100Base-TX copper environments. Operating at Layer 1, the physical layer, data is passed through the converter at line speed, making it ideal for applications where low latency is essential.
Main Features
- Stand-alone media converter
- Interfaces 100Base-TX and 100Base-FX
- Integrates fiber optic cabling
- Operates at Layer 1 for low latency
- Passes data at line speed
- Ideal for low latency applications
General Information
Name: Lantronix E-100BTX-FX-06-NA Stand-Alone Fast Ethernet Media Converter 100Base-TX to 100Base-FX
Category: Lantronix, Data Comm & Networking, Network Adapters, Media Converters
UPC Code: 648177043675
Country of Origin: Taiwan, Province of China. Country of origin is subject to change.
Specifications
ADI Part Number P6-E1BTXFX6N Brand Name Lantronix Country of Origin TW Manufacturer Transition Networks, Inc Manufacturer Part Number E-100BTX-FX-06-NA Product Name Stand-alone Fast Ethernet Media Converter 100Base-TX to 100Base-FX Product Series E-100BTX-FX-06 Product Type Transceiver/Media Converter
Fiber Optic Mode Multimode Media Type Supported Optical Fiber, Twisted Pair
Network (RJ-45) Yes Number of Network (RJ-45) Ports 1 Number of Ports 2 Number of ST Ports 1
Fiber Optic Wavelength 1300.00nm Network Technology 100Base-FX
Ethernet Technology 100 Mbps (Fast Ethernet)
Depth 5.00" Width 3.00"
Power Source AC Power, DC Power
Mount Type DIN Rail Mount, Freestanding, Rack Mount, Shelf Mount, Wall Mount
ADI Part Number Replaces P6-E100BTXFX Model Number Replaces E-100BTX-FX-05-NA
Limited Warranty Lifetime
Environmental Certification RoHS, WEEE Environmentally Friendly Yes Package Contents - Stand-alone Fast Ethernet Media Converter 100Base-TX to 100Base-FX
- Power Supply (North America)
