GRI 29CXWG-B Surface Mount Magnetic Reed Switch Set, SPDT, Extra Wide Gap Up to 2", Top Terminals, Covers, Brown
29CXWG-B|GI-29CXWGB
GRI 29CXWG-B Surface Mount Magnetic Reed Switch Set, SPDT, Extra Wide Gap Up to 2", Top Terminals, Covers, Brown
29CXWG-B|GI-29CXWGB
George Risk Industries
GRI 29CXWG-B Surface Mount Magnetic Reed Switch Set, SPDT, Extra Wide Gap Up to 2", Top Terminals, Covers, Brown
29CXWG-B | GI-29CXWGB
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
This series offers a standard gap of 1", a wide gap of up to 1.5" and an extra wide gap of 2" and can be installed on a steel surface with a minimum gap penalty. The "P" style is a pre-wired switch with 2' of conductor cable. A broad range of mounting brackets are also available. See spec. sheet in accessory section of our catalog.
Main Features
General Information
Name:GRI 29CXWG-B Surface Mount Magnetic Reed Switch Set, SPDT, Extra Wide Gap Up to 2", Top Terminals, Covers, Brown
Category:George Risk Industries, Intrusion, Alarm Contacts, Magnetic Contacts
UPC Code:697625007318
Country of Origin:United States. Country of origin is subject to change.
Specifications
ADI Part Number GI-29CXWGB Brand Name George Risk Industries Manufacturer Part Number 29CXWG-B
Color Brown
Contact Type SPDT
Limited Warranty Lifetime Warranty
Country of Origin US Features 24" #22AWG 2 conductor jacketed lead on 29PA, Built in E.O.L. Resistors and Diodes upon request, Colors- white, brown and gray, Concealed screw terminals on 28 series, Covers, spacers and mounting hardware included, Hermetically sealed, Longer leads on 29PA upon request, Plated contacts resist sticking or freezing, Private labeling upon request, Screw down flanges, Side screw terminals on 29 series, Supervisory loops and dummy terminals upon request, Surface mount magnetic contact, Switches and magnets available separately, This versatile series sets the industry standard for commercial and light industrial applications
