EtherWAN EX78822-VVBT Hardened Managed Ethernet PoE Switch, 8 Ports, 120W, Black
EX78822-VVBT
|ET-78822VVBT
Shop All EtherWAN
EtherWAN EX78822-VVBT Hardened Managed Ethernet PoE Switch, 8 Ports, 120W, Black
EX78822-VVBT | ET-78822VVBT
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
EtherWAN's EX78000 Series is a hardened DIN-rail mounted managed PoE Ethernet switch platform. Equipped with 8 10/100BASE-TX PoE ports along with 60W power and 2 gigabit fiber ports, the EX78000 Series provides flexibility, speed, and reliability for networks in urban infrastructure, transportation, security, and other areas where connectivity is crucial.
Main Features
General Information
Name: EtherWAN EX78822-VVBT Hardened Managed Ethernet PoE Switch, 8 Ports, 120W, Black
Category: EtherWAN, Data Comm & Networking, Hubs, Routers & Switches, Network Switches
UPC Code:
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number ET-78822VVBT Brand Name EtherWAN Manufacturer Part Number EX78822-VVBT
Material Metal Power Consumption 10.4W
Manageable Yes
Networking Standards IEEE 802.1p, IEEE 802.1Q, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
ADI Part Number Replaces ET-EX78822AV, ET-EX78822VV Model Number Replaces EX78822-AVB, EX78822-VVB
Depth 5.6" Height 6.8" Width 2.8"
Input Voltage 52-57V DC PoE Budget 240W Power Source PoE
Mount Type DIN Rail Mount
Limited Warranty Lifetime Warranty
Environmental Certification FCC, UL Environmentally Friendly Yes Features Available with either copper, SC, ST, WDM or SFP interface, Dual firmware image support, PoE power budget up to 60W/port (Ultra PoE), total 240W Package Contents 1 Console Cable, Ethernet Switch, Quick install guide
