Image of 8A-ACMXNETWP
Acheter AV Pro Edge

AV Pro Edge AC-MXNET-1G-EV2WP MXNet 1G Evolution II Wall Plate Encoder with USB-C and HDMI Input, White

AC-MXNET-1G-EV2WP|8A-ACMXNETWP
Acheter AV Pro Edge

AV Pro Edge AC-MXNET-1G-EV2WP MXNet 1G Evolution II Wall Plate Encoder with USB-C and HDMI Input, White

AC-MXNET-1G-EV2WP|8A-ACMXNETWP

Se connecter prix revendeur

Devenir client ADI
AV Pro Edge

AV Pro Edge AC-MXNET-1G-EV2WP MXNet 1G Evolution II Wall Plate Encoder with USB-C and HDMI Input, White

AC-MXNET-1G-EV2WP | 8A-ACMXNETWP

Veuillez vous connecter pour voir les tarifs, consulter la disponibilité des produits et ajouter des articles à votre panier.

Aperçu
Spécifications
Documents

Aperçu

The AC-MXNET-1G-EV2WP is an MXnet Evolution II encoder designed for precise multicast encoding of A/V signals with selectable switching between HDMI and USB-C inputs. This encoder supports native 4K/60 fps video at up to 4:4:4 chroma subsampling, including HDR and Dolby Vision with 8-, 10-, and 12-bit color depths, and handles 3D immersive audio formats such as Dolby Atmos and DTS:X. Packaged as a low-profile NEMA double-gang wall plate, it is PoE powered and fits standard wall boxes, offering locally selectable inputs and minimal heat and power consumption. The device includes features like RS-232 control routing, status LED control, and generates a preview thumbnail for HDMI video sources, making it suitable for installations in desks, lecterns, or secured environments where clean, flexible operation is critical.

Principales caractéristiques

  • Supports native 4K/60 fps video bandwidth with 4:4:4 chroma subsampling and 8-,10-, and 12-bit
  • Includes selectable HDMI and USB-C inputs with analog audio follow
  • Uses proprietary M-JPEG codec for artifact-free, visually lossless image fidelity
  • Supports 3D immersive audio formats including Dolby Atmos and DTS:X for IMAX Enhanced via HDMI
  • USB 2.0 Type-B and USB-C inputs enable computer and peripheral connectivity with bi-directional USB
  • Powered by PoE without a transformer, fitting standard NEMA double-gang wall boxes
  • Features device light control with status LEDs adjustable via MXnet Mentor software
  • Low latency encoding with minimal heat and low power consumption
  • RS-232 control routing with MXnet Mentor software for downstream EVO II decoder command mapping

    • Renseignements généraux

    Nom:AV Pro Edge AC-MXNET-1G-EV2WP MXNet 1G Evolution II Wall Plate Encoder with USB-C and HDMI Input, White
    Category:AV Pro Edge, Pro AV, Commercial Audio, Pro Wall Plates
    UPC Code:810108230748
    Country of Origin:China. Country of origin is subject to change.

    Spécifications

    Documents et ressources sur les produits

    Fiche de produit
    Manuel de l`utilisateur
