Product Overview
Passive infrared motion detector with form C alarm contact and tamper. The Bravo 3 is recommended for larger residential, commercial & industrial installations that require extended range sensing without any compromise in accuracy.
Features
- Exceptional catch performance at elevated temperatures
- Sensitivity adjustment to configure the detector for normal or hostile environments
- High-level static and transient protection
- Multi-Level Signal Processing
- Dual element low noise sensor
- Four interchangeable lenses
- High level static protection
- High level transient protection
- High level of White Light Immunity
- Excellent RF immunity
- Temperature compensation
- Fast / slow detection jumper
- LED on / off jumper
- Vertical adjustment
- SMD construction
- Super quiet operation
- Wall / corner mounting
General Information
Name : DSC BV-302 Digital Bravo PIR Passive Infrared Motion Detector, Form 'C' Relay Contact and Tamper Switch , DSC
Category : PIR Motion Sensors
UPC Code : 80006156
Country of Origin : Canada. Country of origin is subject to change.
Specifications
General Information
ADI Part Number : 3W-BV302
Brand Name : DSC
Manufacturer : Johnson Controls
Manufacturer Part Number : BV-302
Product Line : Security, Survelliance
Product Model : BV-302
Product Name : Bravo BV-302 Motion Sensor
Product Series : Bravo 3
Product Type : Motion Sensor
Technical Information
Maximum Motion Sensing Distance : 60'
Maximum Motion Sensing Distance (mm) : 18300
Maximum Viewing Angle : 90°
Minimum Motion Sensing Distance : 49.87 ft (15200 mm)
Minimum Motion Sensing Distance (mm) : 15200
Passive Infrared Sensor (PIR) : Yes
Physical Characteristics
Application/Usage : Indoor
Color : White
Depth : 1.87" (47.50 mm)
Depth (mm) : 47.498
Form Factor : Corner Mount, Wall Mount
Height : 3.50" (88.90 mm)
Height (mm) : 88.9
Width : 2.50" (63.50 mm)
Width (mm) : 63.5
Power Description
Input Voltage : 14.5V DC
Input Voltage (V DC) : 14.5
Power Source : DC
Product Information
Installation Type : Hybrid
Mount Type : Corner Mount, Wall Mount
Miscellaneous
Features : Dual Tech
Indoor/Outdoor : Indoor
