Platinum Tools 105020 EZ-RJ45 STP CAT5e/CAT6 Connector Internal Ground

105020 | TS-105020

Please sign in to view pricing and availability and to add to cart.

Overview
Specifications
Documents

Product Overview

The EZ-RJ45 Pass-Through RJ45 Connectors with internal ground offer a premium solution for data connectivity, packaged in sets of 100 for convenient use. Designed for a maximum cable outer diameter of 0.260" (6.60mm) and a maximum insulation diameter of 0.040” (1.016mm), these connectors are compatible with solid or stranded 24-23AWG twisted pair cables. Featuring 50-micron gold plated contacts, they significantly enhance noise immunity across all frequencies, particularly above 30 MHz, where cable balance tends to degrade. The fully shielded design effectively reduces both pair-to-pair and alien crosstalk, providing improved performance. With a unique pass-through design, the connectors allow for optimal maintenance of cable twists, which minimizes crosstalk and enhances overall performance. Rated for up to 1G bandwidth, these connectors meet Category 6 performance standards per EIA/TIA B.2, and are FCC compliant, UL rated, and RoHS compliant. They are recommended for data applications only and are not suitable for Power over Ethernet (PoE) applications.

Main Features

  • EZ-RJ45 design allows the wires to pass through the connector so the twists in each pair can be pulled closer to the contacts than conventional plugs
  • Maintaining the twists to the point of termination significantly decreases crosstalk and markedly increases performance
  • Fully shielded products provide reduced pair-to-pair crosstalk, alien crosstalk, and considerably improved i mmunity to noise at all frequencies
  • Significantly improve Shannon capacity
  • Substantially improve noise immunity at all frequencies, especially above 30 MHz when cable balance starts to significantly degrade
  • Category 6 performance per EIA/TIA B.2. FCC compliant, UL rated. RoHS compliant
  • Max Cable OD: 6.60mm (0.260"), Max Insulated wire OD: 1.016mm (0.040")
  • For solid round or stranded wire cables
  • TAA Compliant
  • Made in USA

    • General Information

    Name:Platinum Tools 105020 EZ-RJ45 STP CAT5e/CAT6 Connector Internal Ground
    Category:Platinum Tools, Tools & Hardware, Tools, Crimping & Punch Down Tools, ADI Pro Rewards
    UPC Code:849160003755
    Country of Origin:United States. Country of origin is subject to change.

    Specifications

    Product Documents and Resources

    Product Data Sheet
