Securitron PB3EA 3/4" Receptacle Alternate Economy 3A Double Pole Single Throw, 1-Gang
PB3EA
|SN-PB3EA
Shop All Securitron by ASSA ABLOY
Securitron PB3EA 3/4" Receptacle Alternate Economy 3A Double Pole Single Throw, 1-Gang
PB3EA | SN-PB3EA
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
High quality Push Buttons are available in a broad selection of colors, sizes, switch types and outputs.With a wide range of options for interchangeable lenses and field convertible outputs, push buttons can release any lock, alone or in conjunction with door closers and other hardware.
Main Features
- Includes switchable green and red lenses
- Red LED on plate where applicable
- 3 Amp rated contacts
- Stainless Steel single gang plate: 4.5" x 2.75" [114mm x 70mm]
- Stainless Steel narrow stile plate: 4.5" x 1.75" [114mm x 44mm]
- Surface Mount: 3.875" x 2" [98mm x 51mm]
- Field convertible from DPST to DPDT
General Information
Name: Securitron PB3EA 3/4" Receptacle Alternate Economy 3A Double Pole Single Throw, 1-Gang
Category: Securitron by ASSA ABLOY, Access Control, Egress Devices & Alarms, Door Release Buttons
UPC Code: 784607023326
Country of Origin: United States. Country of origin is subject to change.
Specifications
ADI Part Number SN-PB3EA Brand Name Securitron by ASSA ABLOY Country of Origin US Manufacturer Part Number PB3EA Switch Action Momentary
LED Indicator Bi-Color LED
Maximum Operating Temperature 110.00°F Minimum Operating Temperature 32.0°F
Depth 0.63" Height 4.50" Width 2.75"
Voltage Rating 12V DC, 24V DC
Contact Type DPDT (Double Pole Double Throw)
