Panduit CTAP4/0-2-X Copper Compression Connector Tap, 3-Pack, Heavy Duty
CTAP4/0-2-X|P9-CTAP402X
Panduit CTAP4/0-2-X Copper Compression Connector Tap, 3-Pack, Heavy Duty
CTAP4/0-2-X|P9-CTAP402X
Panduit
Panduit CTAP4/0-2-X Copper Compression Connector Tap, 3-Pack, Heavy Duty
CTAP4/0-2-X | P9-CTAP402X
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
The CTAP4/0-2-X Compression Connector Tap provides high-strength and premium electrical properties. It is suitable for use with solid and stranded copper Code conductors for tapping into unbroken continuous main, as a wire joint or two-way splice. The wide wire range-taking capability minimizes inventory requirements. UL listed per ul 486 for use up to 35 kv and temperature rated 90°c when crimped with Panduit and specified competitor crimping tools and dies.
Main Features
General Information
Name:Panduit CTAP4/0-2-X Copper Compression Connector Tap, 3-Pack, Heavy Duty
Category:Panduit, Batteries & Power Supplies, Power Accessories & Parts
UPC Code:074983839506
Country of Origin:. Country of origin is subject to change.
Specifications
ADI Part Number P9-CTAP402X Brand Name Panduit Manufacturer Part Number CTAP4/0-2-X Product Type Grounding Connector
Material Copper
Height 1.7" Thickness 1.1" Width 1.1"
Length 0.9"
Limited Warranty 1-Year
Compatibility - For Use With: AWG wire only
- Application: Utility/Ground Grid
