Middle Atlantic PDX-615C-SP NEXSYS 6-Outlet Compact PDU, Series Surge Protection, 15A
PDX-615C-SP
|NO-PDX615CSP
Acheter Middle Atlantic by Legrand
Middle Atlantic PDX-615C-SP NEXSYS 6-Outlet Compact PDU, Series Surge Protection, 15A
PDX-615C-SP | NO-PDX615CSP
Veuillez vous connecter pour voir les tarifs, consulter la disponibilité des produits et ajouter des articles à votre panier.
Aperçu
Spécifications
Documents
Aperçu
The Middle Atlantic PDX-615C-SP is a compact NEXSYS PDU designed for 'behind-the-display' applications, particularly digital signage. It features (6) NEMA 5-15R outlets and operates at 15A. The PDU offers flexible mounting options with both clamp and L-brackets, which can be easily attached to a Lever Lock plate for tool-free installation inside a rack, kiosk, or in-wall box. It. Includes Series stage MOV surge protection with 3 stages and visual indicators of surge status on the front and side. The selectable on/off voltage protection from the dry contact port helps safeguard sensitive equipment from over/under voltage scenarios by automatically turning off the outlets during such events and restoring them once the power is within the acceptable range. The PDU also supports cleaner cable management with a standard 2ft power cord and allows for the use of both outlets without obstruction, thanks to the orientation designed for easier plugging of DC transformers (wall warts).
Principales caractéristiques
- 15A with (6) NEMA 5-15R Outlets
- The compact design of this NEXSYS PDU is perfect for “behind-the-display” applications, especially digital signage
- It’s very flexible. The NEXSYS Compact PDU. Includes (2) mounting options for mounting flexibility, a clamp and L-brackets
- Easily attach both mounting solutions to a Lever Lock plate for tool-free mounting inside a rack, kiosk, in-wall box, etc.
- Enhanced Series Surge Protection
- Industry’s fastest patented non-degrading surge technology
- Protects equipment with out contaminating system ground
- Industry-leading 12 year warranty
- 100% MOV-free design – unlike any competitive offering
- Worried about the under/over voltage? Don't. with the selectable on/off voltage protection from the dry contact port, it gives the option to protect sensitive equipment from over/under voltage scenarios
Renseignements généraux
Name: Middle Atlantic PDX-615C-SP NEXSYS 6-Outlet Compact PDU, Series Surge Protection, 15A
Category: Middle Atlantic by Legrand, Batteries & Power Supplies, Power Management, Power Distribution Units
UPC Code: 656747396489
Country of Origin: Malaysia. Country of origin is subject to change.
Spécifications
ADI Numéro du produit NO-PDX615CSP Code fabricant PDX-615C-SP Fabricant Legrand Group Gamme NEXSYS Marque Middle Atlantic by Legrand Modèle de produit PDX-615C-SP Nom de produit NEXSYS PDX-615C-SP 6-Outlets PDU Pays d'origine MY Secteur AV résidentiel Série de produit PDX Type de produit Commutateur KVM
Ampérage 15.00A Détail du réceptacle 6 x NEMA 5-15R Tension de sortie 120V AC Type de PDU Switched Type de Prise/Module Enfichable NEMA 5-15R
Certifications UL Listed Conforme aux normes TAA No
Format Rack Hauteur 1.74" Profondeur 7.00"
Courant d'entrée 15.00A Tension d'entrée 120V AC Type de connecteur/prise NEMA 5-15P
Type de montage Rack Mount, Wall Mount Type de protection Surge Protection
Garantie Limitée 12-Year
Caractéristiques Compact Contenu de l'emballage - NEXSYS PDX-615C-SP 6-Outlets PDU
- Clamp
- L-brackets
- Standard 2' Cord
