Image of CM-753620
Shop all Camden Door Controls

Camden CM-7536/20 36" Column Switch with Wheelchair and Foot Icon Blue Film, Aluminium

CM-7536/20|CM-753620
Shop all Camden Door Controls

Camden CM-7536/20 36" Column Switch with Wheelchair and Foot Icon Blue Film, Aluminium

CM-7536/20|CM-753620

Sign In for Dealer Pricing

Become an ADI Customer
Camden Door Controls

Camden CM-7536/20 36" Column Switch with Wheelchair and Foot Icon Blue Film, Aluminium

CM-7536/20 | CM-753620

Please sign in to view pricing and availability and to add to cart.

Overview
Specifications
Documents

Product Overview

CM-74 and CM-75 Series Column switches offer greater user convenience and lower installation costs by providing a single activation device in place of 2 high / low switches, as required by a growing number of building codes across North America. These Column switches feature solid aluminum or stainless steel construction and are available in a range of finishes. Also available is the option for Kinetic by Camden no-battery wireless or Lazerpoint battery powered wireless transmitters. The VR Series Column switches with hands-free sensors use active infra-red technology to eliminate the spread of germs.

Main Features

  • Low profile contoured design with easy activation from side angles
  • Meets or exceeds California building code, section 1117B.6 requirements
  • 2 Fully redundant SPDT, 15A UL listed switches
  • Lazerpoint wireless compatible with provision for 'snap-in' battery powered transmitter
  • Adjustable leveling screws for easy installation on uneven walls
  • No internal wires exposed to moving parts
  • Built-in Kinetic(tm) no-battery wireless transmitter
  • 300' (Open air) wireless range
  • 500,000 Cycles
  • Red / green light ring with switch or remote activation

    • General Information

    Name:Camden CM-7536/20 36" Column Switch with Wheelchair and Foot Icon Blue Film, Aluminium
    Category:Camden Door Controls, Access Control, Door Hardware, Door Push Plates
    UPC Code:670454216304
    Country of Origin:Canada. Country of origin is subject to change.

    Specifications

    Product Documents and Resources

    Product Data Sheet
    Installation Instructions
