AVPro Edge AC-BTSSF-10KUHD-100 10K 48Gbps AOC High Speed HDMI Cable, 100m

AC-BTSSF-10KUHD-100|8A-10KUHD100
Shop all AVPro Edge

AVPro Edge AC-BTSSF-10KUHD-100 10K 48Gbps AOC High Speed HDMI Cable, 100m

AC-BTSSF-10KUHD-100|8A-10KUHD100

Sign In for Dealer Pricing

Become an ADI Customer
Image of 8A-10KUHD100
AVPro Edge

AVPro Edge AC-BTSSF-10KUHD-100 10K 48Gbps AOC High Speed HDMI Cable, 100m

AC-BTSSF-10KUHD-100 | 8A-10KUHD100

Please sign in to view pricing and availability and to add to cart.

Overview
Specifications
Documents

Product Overview

Bullet Train HDMI 2.1 cables are advanced active optical cables designed for mission-critical audio/video environments requiring stability and high performance. These cables deliver data at speeds up to 48 Gbps and support high frame rates of up to 120 fps, with low latency and up to 20% less delay than passive copper HDMI cables. Certified by the Imaging Science Foundation (ISF) and CMP/Plenum rated, they support resolutions up to 10K and technologies including FRL, VRR, Ethernet, HDR, Dolby Vision, and 7.1 Dolby Audio including Atmos. The cable includes Cleerline SSF fiber optic strands capable of over 100 Gbps for future-proofed use, requires HDMI port power or supplemental USB power, and is rated for in-wall installation with extensive certification for safety and environmental standards.

Main Features

  • 48 Gbps bandwidth supporting up to 120 fps/hz
  • CMP and Plenum cable rating for in-wall installation
  • Supports FreeSync/LFC (FRL) and Variable Refresh Rate (VRR)
  • Compatible with 4K, 5K, 8K and 10K resolutions
  • Includes Ethernet channel and supports 10 and 12 bit color depths
  • ARC support for 5 - 60 m cables and eARC for 5 - 20 m cables
  • Low latency transmission with up to 20% less latency than passive copper HDMI cables
  • Supports HD resolutions, 3D signals, VESA resolutions, HDR and Dolby Vision
  • Audio support for 7.1 Audio, Dolby Audio (including Atmos), and DTS Audio
  • Certified to UL 444/CSA C22.2 No. 214, CE, FCC, ISF certified, RoHS, REACH, CMP, and Prop65

    • General Information

    Name:AVPro Edge AC-BTSSF-10KUHD-100 10K 48Gbps AOC High Speed HDMI Cable, 100m
    Category:Pro AV, Commercial Connector Cables, Pro HDMI Cables
    UPC Code:850001710985
    Country of Origin:China. Country of origin is subject to change.

    Specifications

    Product Documents and Resources

    Product Data Sheet
    Manufacturer Brochure
