Product Overview
The Fire-Lite MMF-300A is an addressable monitor module for Fire-Lite addressable fire alarm control panels. It is is a standard-sized module (typically mounts to a 4"" [10.16 cm] square box) that supervises either a Style D (Class A) or Style B (Class B) circuit of dry-contact input devices, such as conventional heat detectors and pull stations.
The MMF-300(A) Monitor Module is intended for use in intelligent, two-wire systems, where the individual address of each module is selected using the built-in rotary switches. It provides either a two-wire or four-wire fault-tolerant Initiating Device Circuit (IDC) for normally-open-contact fire alarm and supervisory devices. The module has a panel-controlled LED indicator. The MMF-300(A) can be used to replace M300(A)modules in existing systems.
General Information
Name : Fire-Lite MMF-300A Standard-Sized Addressable Monitor Module for Style (Class A) or Style (Class B) Circuit of Dry-Contact Input Devices , Fire-Lite Alarms by Honeywell
Category : Control Panel Modules
UPC Code : 783863014369
Country of Origin : United States. Country of origin is subject to change.
Specifications
General Information
ADI Part Number : FL-MMF300A
Manufacturer Part Number : MMF-300A
Product Model : MMF-300A
Product Name : MMF-300A Addressable Control Module
Product Series : MMF
Product Type : Addressable Monitor Module
Physical Characteristics
Depth : 1.25" (31.75 mm)
Height : 4.50" (114.30 mm)
Width : 4" (101.60 mm)
Miscellaneous
Package Contents : <ul><li>MMF-300A Addressable Control Module</li><li>Installation Instructions</li><li>Mounting Hardware</li></ul>
