Product Overview
Camden introduces the first surface mount RIM strike with preload in the security industry. CX-EPD1289L grade 1 surface mount RIM strike, with latch monitoring, also offers a 'Universal' strike design that delivers unparalleled application flexibility, with both UL security and fire listings.
Preload is pressure exerted on the keeper of a strike that causes the mechanism to fail to release. Whether caused by air pressure, a misaligned door, or inexact installation, CX-EPD1289L RIM strikes are designed to operate where other strikes fail!
General Information
Name : Camden CX-EPD1289L Surface Mount Preload Grade RIM Strike, 12/24V, AC/DC, (Replaces CX-ED1259L) , Camden Door Controls
Category : Electric Strikes
UPC Code : 670454208385
Country of Origin : Germany. Country of origin is subject to change.
Specifications
General Information
ADI Part Number : CM-CXEPD1289
Brand Name : Camden
Manufacturer : Camden Door Controls
Manufacturer Part Number : CX-EPD1289L
Product Name : Surface Mount Preload RIM Strike
Product Type : Electric Strike
Technical Information
Compatible Door Lock Type : Latch Lock
Duty Cycle : 250000
Electric Strike Assembly : Body Only
Holding Strength : 680.39 kg
Holding Strength (g) : 680388.555
Security Configuration : Fail Safe, Fail Secure
Physical Characteristics
Application/Usage : Door
Color : Silver
Product Material : Stainless Steel
Strike Depth : 0.78" (19.80 mm)
Strike Depth (mm) : 19.8
Strike Length : 9.12" (231.60 mm)
Strike Length (mm) : 231.6
Strike Width : 1.89" (48 mm)
Strike Width (mm) : 48
Power Description
Input Current : 280 mA, 560 mA
Input Current (A) : 0.28, 0.56
Input Voltage : 12V AC, 12V DC, 24V AC, 24V DC
Input Voltage (V AC) : 12, 24
Input Voltage (V DC) : 12, 24
Warranty
Limited Warranty : 5 year
Miscellaneous
Additional Information : <ul> <li>Dynamic Strength: 70 ft-lbs</li> <li>Endurance: 1,000,000 Cycles (Factory Tested)</li> <li>Operation: AC Buzz, DC Silent</li> <li>Duty: Continuous</li> <li>Latch Monitor: SPDT, 100mA @ 24V DC, Resistive</li> </ul>
Certifications & Standards : <ul> <li>UL</li> <li>UL10C/CAN4-S104</li> </ul>
Features : Fire Resistant, Heavy Duty, Static Strength, Surface Mount
Package Contents : <ul> <li>Surface Mount Preload RIM Strike</li> <li>Metal Mounting Jig</li> <li>Latch Monitoring Switch</li> </ul>
