Tripp Lite SRWO12US SmartRack Flat-Pack Low-Profile Switch-Depth Wall Mount Pivoting Open Frame Rack, 18" (46cm), 150lb (68kg), 2-Post, 12U

Brand: Tripp Lite by Eaton
ADI #:TC-SRWO12US Model #: SRWO12US  Name: Tripp Lite SRWO12US SmartRack Flat-Pack Low-Profile Switch-Depth Wall Mount Pivoting Open Frame Rack, 18" (46cm), 150lb (68kg), 2-Post, 12U
  • Maximum load capacity of 150 lb.
  • Pivots to allow easy rear access to equipment and cabling
  • Stores 12U of 19 in. rack equipment up to 18 in. deep
Tripp Lite 12U Wall Mount Pivoting 2-Post Open Frame Rack Cabinet Hinged

Product Overview

The SRWO12US SmartRack 12U Flat-Pack Low-Profile Switch-Depth Wall-Mount Pivoting 2-Post Open Frame Rack stores and organizes EIA-standard 19-inch rack equipment compatible with 2-post mounting in network wiring closets, back offices and other secure areas with limited floor space where a locked enclosure is not required. Constructed from heavy-duty steel with a durable black powder-coated finish, the rack has a maximum load capacity of 150 pounds.The open frame design pivots to allow unrestricted access for installing, configuring and servicing equipment and cabling from any direction. The rack is simple to assemble and mount to the wall. Threaded 12-24 mounting holes and numbered rack spaces make equipment installation easy. Included locking pins secure the frame in position while pivoted for mounting equipment. The vertical mounting rails accommodate equipment up to 18 inches deep, such as network switches and patch panels. Assembly and equipment-mounting hardware is included.

General Information

Name : Tripp Lite SRWO12US SmartRack Flat-Pack Low-Profile Switch-Depth Wall Mount Pivoting Open Frame Rack, 18" (46cm), 150lb (68kg), 2-Post, 12U , Tripp Lite by Eaton
Category : Rack Cabinets & Frames
UPC Code : 037332156761
Country of Origin : China. Country of origin is subject to change.

Specifications

General Information

ADI Part Number : TC-SRWO12US
Brand Name : Tripp Lite
Manufacturer : Tripp Lite by Eaton
Manufacturer Part Number : SRWO12US
Product Line : SmartRack
Product Model : SRWO12US
Product Name : SmartRack SRWO12US Wall-Mount Pivoting Open Rack Frame
Product Type : Rack Frame

Physical Characteristics

Depth : 20.35" (516.89 mm)
Depth (mm) : 516.89
Form Factor : Wall Mount
Height : 30.45" (773.43 mm)
Height (mm) : 773.43
Product Material : Steel
Rack Height : 12U
Width : 19.76" (501.90 mm)
Width (mm) : 501.904

Warranty

Limited Warranty : 5 year

Miscellaneous

Environmental Certification : ROHS
Environmentally Friendly : Yes
